Picture/Display
• Diagonal screen size: 74.5 inch / 189.3 cm
• Panel resolution: 3840 x 2160
• Optimum resolution: 3840 x 2160 @ 60 Hz
• Brightness: 350 cd/m²
• Response time (typical): 10 ms
• Aspect ratio: 16:9
• Viewing angle (H / V): 178 / 178 degree
• Pixel pitch: 0.4296 (H) x 0.4296 (V)[mm]
• Display colors: 1.07 B
• Picture enhancement: 3/2 - 2/2 motion pull down,
3D Combfilter, Motion compens. deinterlacing,
Progressive scan, 3D MA deinterlacing, Dynamic
contrast enhancement
• Surface treatment: Anti-Glare coating
• Panel technology: ADS
• Contrast ratio (typical): 1200:1
• Operating system: Android 8.0
Supported Display Resolution
• Computer formats
640 x 480 60,67,75Hz
720 x 400 70Hz
800 x 600 60Hz
832 x 624 75Hz
1024 x 768 60Hz
1152 x 870 75Hz
1280 x 720 60Hz
1280 x 1024 60Hz
1440 x 900 60Hz
1600 x 900 60Hz
1680 x 1050 60Hz
1920 x 1080 60Hz
3840 x 2160 30, 60Hz
• Video formats
480i 60Hz
480p 60Hz
576p 50Hz
576i 50Hz
720p 50, 60Hz
1080i 50, 60Hz
1080p 50, 60Hz
2160p 30, 60Hz
Connectivity
• Video input: DVI-D (x1), HDMI 2.0 (x3), VGA
(Analog D-Sub) (x1), USB 2.0 (x4), USB-C (up to
65W)
• Audio input: 3.5 mm mini jack (x1)
• Audio output: 3.5 mm Mini Jack (x1)
• External control: IR (in/out) 3.5 mm jack, RJ45,
RS232C (in/out) 2.5 mm jack
• Other connections: OPS, micro SD, USB-B (x3)
Convenience
• Placement: Landscape (18/7)
• Screen saving functions: Pixel Shift, Low Brightness
• Signal loop through: RS232, IR Loopthrough
• Ease of installation: AC Out
• Energy saving functions: Smart Power
• Network controllable: RS232, RJ45
• Keyboard control: Lockable
• Remote control signal: Lockable
• Other convenience: Carrying handles
Operating conditions
• Temperature range (operation): 0 ~ 40 °C
• Temperature range (storage): -20~60 °C
• Altitude: 0 ~ 3000 m
• MTBF: 50,000 hour(s)
• Humidity range (operation)[RH]: 20 ~ 80%
(without condensation)
• Humidity range (storage) [RH]: 5 ~ 95% (without
condensation)
Power
• Consumption (Typical): 155 W
• Consumption (Max): 400 W
• Standby power consumption: <0.5W
• Mains power: 100 ~ 240 VAC, 50/60Hz
• Power Saving Features: Smart Power
• Energy Label Class: G
Sound
• Built-in speakers: 2 x15 W
Accessories
• Optional accessories: Interact dongles
• Included Accessories: Cleaning cloth (x1), HDMI
Cable (3m) (x1), IR sensor cable (1.8 m) (x1),
Philips logo (x1), Quick start guide (x1), Remote
control & AAA batteries, RS232 daisy chain cable
(x1), Touch Pen (x2), USB A to B cable (3m) (x1),
USB Cover and screw (x2), RS232 cable, AC
Power Cord, Cable clip (x3), AC switch cover &
Screw x1, DVI-D cable
Miscellaneous
• On-Screen Display Languages: Arabic, Dutch,
Danish, English, French, Finnish, German, Italian,
Japanese, Norwegian, Polish, Portuguese, Russian,
Spanish, Swedish, Simplified Chinese, Turkish,
Traditional Chinese
• Regulatory approvals: CE, FCC, Class A, RoHS,
CB, EAC, EMF, ETL
• Warranty: 3 year warranty
Multimedia Applications
• USB Playback Video: H.263, H.264, H.265, MPEG1/
2, MPEG4
• USB Playback Picture: BMP, JPEG, PNG
• USB Playback Audio: AAC, MPEG, HEAAC
Interactivity
• Multi-touch technology: Advanced infrared touch
• Touch points: 20 simultaneous touch points
• Plug and play: HID compliant
• Protection glass: Anti-Glare, Tempered safety glass
7MOHS
Weight
• Product with packaging (kg): 67.60 kg
• Product with packaging (lb): 149.03 lb
• Product without stand (kg): 55.77 kg
• Product without stand (lb): 122.95 lb
Internal Player
• CPU: 2 x A53 + 2 x A73
• GPU: ARM Mali G51
• Memory: 3GB DDR3
• Storage: 16GB EMMC
Dimensions
• Smart Insert mount: 100x100mm, 6xM4L6
• Set dimensions (W x H x D):
1715.5 x 1007.6 x 101.5mm(D_Max)/
79.2mm(D_Wallmount) mm
• Set dimensions in inch (W x H x D):
67.54 x 39.67 x 3.99(D_Max)/
3.12(D_Wallmount) inch
• Bezel width: 17.8mm(T/R/L) x 31.7mm(B)
• Wall Mount: 600 x 400 mm, M8
• Weight: 55.77 kg
|
