BQ67, Intel 7th gen Desktop CPU, Dual Display media player

Giada Technology Inc.

BQ67, Intel® LGA1151 Socket 6th/7th Gen. Processor

In stock

SKU
BQ67
$220.00

Have a Question about this product?

This form is protected by reCAPTCHA - the Google Privacy Policy and Terms of Service apply.

Description / BQ67, Intel 7th gen Desktop CPU, Dual Display media player

Despite its compact size, the BQ67 is a surprisingly versatile and powerful PC that offers desktop CPU performance. The BQ67 provides the power of Intel Core Skylake-S and Kabylake-S series CPUs. This powerful but compact fat client is ideal for applications such as office computers in government or enterprise roles and kiosks in retail.

More Information

Brand Giada Technology Inc.
Specifications
  BQ67
Processor CPU Intel® LGA1151 Socket 6th/7th Gen. Processor
BIOS AMI Source Code
Chipset H110
Memory Type DDR3L
Socket 2 x SO-DIMM
Max Size 32GB
Graphics GPU Intel® HD Graphics 520/620
Graphic Engine Direct3D 2015, OpenGL 4.5, OpenCL 2.1
HDMI 1 x HDMI1.4b (Max.3840x2160 @30Hz)
HDMI 1 x HDMI2.0 (Max.3840x2160 @60Hz)
Network Controller  Intel I219LM Gigabit Ethernet
Interface 1 x RJ45
I/O USB 4 x USB 3.0,6 x USB 2.0
Serial Port 1 x RS232
Audio 1 x AUDIO-OUT, 1 x MIC-IN
M.2  1 x M.2(2242/2280) for SSD
M.2 1 x M.2(2230) for WiFi/BT
Storage SATA 1 x 2.5\" SATA
JAHC Tech WatchDog Timer 0~255 Second Time Out Support
Auto Power On Power Activated Automatically Start
RTC Set Up Independently Every day, A Week as a Cycle
Operation System Windows Windows 7/8.1/10(64-bit)
Linux Supported
Power Power Type DC-IN
Input Voltage 19V/4.74A
Mechanical Dimensions (W × D × H) 180mm x 177mm x 36mm(7.09\"x 6.97\"x 1.42\")
Construction Metal
Mounting(Optional) VESA Mounting Kit (JZ300)
Color Black
Environment Operating Temperature 0℃ ~ 45℃ ( 32 ℉ ~ 113 ℉ ) at 0.7m/s Air Flow
Relative Humidity 95%@40℃ (non-condensing)
Certification Certification CE, FCC Class B, CCC
Description

Despite its compact size, the BQ67 is a surprisingly versatile and powerful PC that offers desktop CPU performance. The BQ67 provides the power of Intel Core Skylake-S and Kabylake-S series CPUs. This powerful but compact fat client is ideal for applications such as office computers in government or enterprise roles and kiosks in retail.
