High mobility with multiple connectivities including WLAN, Bluetooth, NFC
Light Design, Weight only 1Kg with Battery
G-sensor, light sensor, 2M/8M Camera
Option SCR, 1D/2D Barcode scanner
More Information
brand
Avalue Technology Inc
Specifications
System Information
Processor
Intel® Celeron® Processor N3350 (2M Cache, up to 2.4 GHz)
System Memory
Onboard LPDDR4 4GB
Storage
Solid State Drive
M.2 64GB/128GB Solid State Drive
Panel
LCD Size
10.1"
Display Type
WXGA
Resolution
1280x800
Luminance
300 cd/m²
Touch Type
10 Points Projective Capacitive
I/O
USB Port
2 x USB 3.0 Type A
HDMI
1 x HDMI Output
Other
1 x Audio Jack 1 x Micro SD 1 x DC Jack
System Control
LED Indicator
1 x Power
Control Buttons
1 x Power Button 1 x Barcode Scanner Trigger
Data Collection
Camera
2MP Front Camera 8MP Rear Camera With Auto Focus
NFC
ISO/IEC 14443 A/B, 15693/18092, NFCIP-1, NFCIP-2, Support MIFARE and Felica
Barcode Scanner
1D/2D Barcode Scanner (Optional)
Wireless Communication
WLAN
802.11 a/b/g/n/ac
Bluetooth
Bluetooth 5.0
Certifications
Certification Information
Australia RCM Canada ICES-003 / IC China CCC / SRRC Chile SUBTEL Japan VCCI / MIC Taiwan BSMI /NCC USA FCC UK UKCA
EU CE / RED / EN60601-1, EN60601-1-2 : Austria、Belgium, Czech Republic、Denmark、Finland、France、Germany、Greece、Hungary、Ireland、Italy、Latvia、Liechtenstein、Luxembourg、Netherlands、Norway、Poland、Portugal、Romania、Slovakia、Slovenia、Spain、Sweden、Switzerland
0°C to 40°C (32°F to 104°F) 0°C to 30°C (32°F to 86°F) without a dock or wall mount [EN60601] 0°C to 40°C (32°F to 104°F) with a dock or wall mount [EN60601]
Storage Temperature
-20°C to 60°C (-4°F to 140°F)
Operating Humidity
15%~95% Relative Humidity, Non-Condensing
Weight
1Kg
Vibration Test
MIL-STD-810G Method 514.6 Procedure 1
Shock Test
MIL-STD-810G Method 516.6 Procedure 1
IP Rating
IP65
Dimension
281 x 193.3 x 19.95mm
Storage Humidity
5%~90% Relative Humidity, Non-Condensing
Drop
4-Feet Drop on Concrete Floor, MIL-STD-810G 516.6 Procedure IV
Construction
Rubber + Plastic
Software Support
OS Information
Windows 10 IoT 64bit Android 8.1 without NFC
In-Box Accessory
Accessory
+19V 65W Power Adaptor
Component
Microphone
Front Microphone
Ordering Information
Ordering Information
CAXA0-DCA1-S03R : CAXA0 Desktop cradle /USB2.0x3/LAN/DC19V, without Adapter
CAXA0-WMA1-S03R : CAXA0 Wall Mount kit /USB2.0x3/LAN/DC19V, without Adapter
CAXA0-CSA1-S01R : Battery charging station for CAXA0, DC19V/65W Adapter
ACC-CAXA0-HS-01R : Hand Strap for CAXA0
ACC-CAXA0-SS-01R : Shoulder Strap for CAXA0
Description
Key Features:
Semi-rugged design with Intel Celeron N3350
Medical certified
MIL-STD-810G & IP65 certified, 4-feet drop resistance
