DGS-R9812GP-AIO_S Series 20 port managed GbE Switch

Industrial desktop type Layer-3 20-port managed Gigabit Ethernet switch with 8x10/100/1000Base-T(X) ports and 12x100/1000Base-X, SFP socket, LC connector bypass

In stock

SKU
DGS-R9812GP-AIO_S_xx

Have a Question about this product?

This form is protected by reCAPTCHA - the Google Privacy Policy and Terms of Service apply.

Description / DGS-R9812GP-AIO_S Series 20 port managed GbE Switch

  • Supports Layer 3 routing, RIPv2, OSPFv2, static routing function and multicast routing PIM-SM/PIM-DM
  • Supports O-Ring (recovery time < 30ms over 250 units of connection) and MSTP(RSTP/STP compatible) for Ethernet Redundancy
  • Open-Ring support the other vendor's ring technology in open architecture
  • O-Chain allow multiple redundant network rings
  • *note Support standard IEC 62439-2 MRP (Media Redundancy Protocol) function
  • Provide two optical bypass function
  • Support IEEE 1588v2 clock synchronization
  • Supports IPV6 new internet protocol version

*NOTE: This function is available by request only

More Information

Specifications
Physical Ports
10/100/1000Base-T(X) Ports in RJ45 Auto MDI/MDIX 8
100/1000Base-X with SFP port 12
LC Bypass Port Type Single-Mode Multi-Mode
Technology
Ethernet Standards

IEEE 802.3 for 10Base-T
IEEE 802.3u for 100Base-TX and 100Base-FX
IEEE 802.3ab for 1000Base-T
IEEE 802.z for 1000Base-X
IEEE 802.3x for Flow control
IEEE 802.3ad for LACP (Link Aggregation Control Protocol )
IEEE 802.1p for COS (Class of Service)
IEEE 802.1Q for VLAN Tagging
IEEE 802.1w for RSTP (Rapid Spanning Tree Protocol)
IEEE 802.1s for MSTP (Multiple Spanning Tree Protocol)
IEEE 802.1x for Authentication
IEEE 802.1AB for LLDP (Link Layer Discovery Protocol)
MAC Table 8K
Priority Queues 8
Processing Store-and-Forward
Switch Properties

Switching latency: 7 us
Switching bandwidth: 40Gbps
Max. Number of Available VLANs: 256
IGMP multicast groups: 128 for each VLAN
Port rate limiting: User Define
Https / SSH enhance network security
Jumbo frame Up to 9.6K Bytes
Security Features

Device Binding security feature
Enable/disable ports, MAC based port security
Port based network access control (802.1x)
Single 802.1x and Multiple 802.1x
MAC-based authentication
QoS assignment
Guest VLAN
MAC address limit
TACACS+
VLAN (802.1Q ) to segregate and secure network traffic
Radius centralized password management
SNMPv3 encrypted authentication and access security
Web and CLI authentication and authorization
Authorization (15 levels)
IP source guard
Https / SSH enhance network security
Software Features

Hardware routing, RIP and static routing
IEEE 1588v2 clock synchronization
IEEE 802.1D Bridge, auto MAC address learning/aging and MAC address (static)
Multiple Registration Protocol (MRP)
RSTP/MSTP (IEEE 802.1w/s)
Redundant Ring (O-Ring) with recovery time less than 30ms over 250 units
TOS/Diffserv supported
Quality of Service (802.1p) for real-time traffic
VLAN (802.1Q) with VLAN tagging
Voice VLAN
IGMP v2/v3 Snooping
IP-based bandwidth management
Application-based QoS management
DOS/DDOS auto prevention
Port configuration, status, statistics, monitoring, security
DHCP Server/Client/snooping
DHCP Relay
Modbus TCP
ARP inspection
SMTP Client
Network Redundancy

O-Ring
Open-Ring
O-Chain
*note MRP
MSTP(STP / RSTP compatible)
RS-232 Serial Console Port RS-232 in RJ-45 connector with console cable. 115200bps, 8, N, 1
LED Indicators
Power Indicator Green : Power LED x 3
R.M. Indicator Green : Indicates that the system is operating in O-Ring Master mode
Ring Indicator Green : Indicates that the system is operating in O-Ring mode
Fault Indicator Amber : Indicates unexpected event occurred
10/100/1000Base-T(X) RJ45 port indicator

Green for Link/Act indicator
Dual color LED for speed indicator : Green for 1000Mbps, Amber for 100Mbps, Off-light for 10Mbps
SFP Fiber port indicator Green for port Link/Act
Fault Contact
Relay Relay output to carry capacity of 1A at 24VDC
Power
Redundant Input Power Dual 100~240V AC power inputs in single power socket
Power Consumption (Typ.) 16 Watts
Overload Current Protection Present
Physical Characteristics
Enclosure IP-30
Dimensions (W x D x H) 300 (W) x 165 (D) x 88 (H) mm(11.81 x 6.5 x 3.47 inch)
Weight (g) 2410g
Environmental
Storage Temperature -40 to 85°C (-40 to 185°F)
Operating Temperature -40 to 70°C (-40 to 158°F)
Operating Humidity 5% to 95% Non-condensing
Regulatory Approvals
EMI FCC Part 15, CISPR (EN55022) class A
EMS IEC61000-4-2 (ESD), IEC61000-4-3 (RS), IEC61000-4-4 (EFT), IEC61000-4-5 (Surge), IEC61000-4-6 (CS), IEC61000-4-8, IEC61000-4-11
Shock IEC60068-2-27
Free Fall IEC60068-2-31
Vibration IEC60068-2-6
Safety EN60950-1
Warranty 5 years
Description
  • Supports Layer 3 routing, RIPv2, OSPFv2, static routing function and multicast routing PIM-SM/PIM-DM
  • Supports O-Ring (recovery time < 30ms over 250 units of connection) and MSTP(RSTP/STP compatible) for Ethernet Redundancy
  • Open-Ring support the other vendor's ring technology in open architecture
  • O-Chain allow multiple redundant network rings
  • *note Support standard IEC 62439-2 MRP (Media Redundancy Protocol) function
  • Provide two optical bypass function
  • Support IEEE 1588v2 clock synchronization
  • Supports IPV6 new internet protocol version

*NOTE: This function is available by request only
