eBOX626-311-FL Fanless Embedded System with Atom x5-E3940
Fanless Embedded System with Intel Atom® x5-E3940 1.8 GHz, HDMI, VGA, 2 GbE LAN, 6 USB, and 3 COM
Key Features:
- Intel Atom® x5-E3940 onboard
- 204-pin DDR3L-1866 SO-DIMM for up to 8GB of memory
- Supports 2 GbE LAN, 3 COM, and 6 USB
- Supports one 2.5” SATA drive bay and mSATA
- Trusted Platform Module (TPM) 2.0
- 2 PCI Express Mini Card slots and 1 SIM slot
- -40°C to +60°C operating temperature range
- Hailo-8™ AI acceleration modules compatible
In stock
- SKU
- eBOX626-311-FL
Have a Question about this product?
Description / eBOX626-311-FL Fanless Embedded System with Atom x5-E3940
The eBOX626-311-FL is powered by the Intel® Atom® processor x5-E3940. The fanless embedded box PC was designed to operate reliably in industrial environments – with an IP40-rated enclosure, extended -40°C to +60°C support, and 3 Grms vibration resistance. To ensure system security, it utilizes the Trusted Platform Module (TPM) 1.2 function. The embedded box computer eBOX626-311-FL is well-suited for industrial controllers, intelligent robotic control, intelligent gateway systems, smart kiosks, visual inspection and data visualization.
More Information
| Brand | Axiomtek | ||||||||||||||||||||||||||||||||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Specifications |
|
||||||||||||||||||||||||||||||||||||||||||||||||||||
| Description | The eBOX626-311-FL is powered by the Intel® Atom® processor x5-E3940. The fanless embedded box PC was designed to operate reliably in industrial environments – with an IP40-rated enclosure, extended -40°C to +60°C support, and 3 Grms vibration resistance. To ensure system security, it utilizes the Trusted Platform Module (TPM) 1.2 function. The embedded box computer eBOX626-311-FL is well-suited for industrial controllers, intelligent robotic control, intelligent gateway systems, smart kiosks, visual inspection and data visualization.
|
