D67 4K Dual Display Media Player

Giada Technology Inc.

REPLACED BY D612

This product is now end of life. There might still be stock available; get in touch with us for more details or suggestions for appropriate replacements.

In stock

SKU
D67
$682.00

Have a Question about this product?

This form is protected by reCAPTCHA - the Google Privacy Policy and Terms of Service apply.

Description / D67 4K Dual Display Media Player

Book size Kabylake high end signage player, Intel 7th generation core processor



·         Intel 7th generation core processor

·         2 x SO-DIMM DDR3L/DDR4 Memory,Up to 32GB

·         1 x DP,1 x HDMI, Supporting 4K Display

·         1 x 2.5” SATA, 1 x mSATA, 1 x M.2 (2242/2280)

·         3 x USB 3.0, 3 x USB2.0, 1 x RS232

·         1 x RJ45,1 x Mini-PCIe for WiFi/BT/3G/4G, 1 x SIM Slot

More Information

Brand Giada Technology Inc.
Specifications
    D67
Processor CPU Intel®Pentium 4415U/Core i3-7100U/Core i5-7200U
Frequency 2.30GHz / 2.40GHz / 2.50GHz(Up to 3.10GHz)
BIOS AMI Source Code
Chipset SOC
Memory Type DDR4/DDR3L
Socket 2 x SO-DIMM
Max Size 32GB
Graphics GPU Intel® HD Graphics 620
Graphic Engine Direct3D 2015, OpenGL 4.5, OpenCL 2.1
DP 1 x DP (Max.4096 x 2304 @60Hz)
HDMI 1 x HDMI (Max.3840x2160 @30Hz)
Network Controller Realtek 8111H  Gigabit Ethernet
Interface 1 x RJ45
I/O USB 3 x USB 3.0,3 x USB 2.0
Serial Port 1 x RS232
Audio 1 x AUDIO-OUT, 1 x MIC-IN
Mini-PCIe1# 1 x Full-size Mini-PCIe for mSATA
Mini-PCIe2# 1 x Full-size Mini-PCIe for WiFi/BT/3G/4G
M.2(2230) 1 x M.2(2242/2280) for SSD
SIM 1 x SIM Slot
Storage SATA 1 x 2.5\"SATA
mSATA 1 x Full-size mSATA
M.2 1 x M.2(2242/2280) for SSD
JAHC Tech WatchDog Timer 0~255 Second Time Out Support
Auto Power On Power Activated Automatically Start
Remote Control By IR Controller for Power On
RTC Set Up Independently Every day, A Week as a Cycle
Operation System Windows Windows 10（64-Bit）
Linux Supported
Power Power Type DC-IN
Input Voltage 19V / 3.42A
Mechanical Dimensions (W × D × H) 189.6mm x 148.3mm x 26mm（7.46\"x 5.84\"x 1.02\"）
Construction Metal
Mounting Desk/Wall Mounting and VESA Mounting Kit (JZ183)
Color Black
Environment Operating Temperature 0℃ ~ 40℃ ( 32 ℉ ~ 104 ℉ ) at 0.7m/s Air Flow
Relative Humidity 95%@40℃ (non-condensing)
Certification Certification CE, FCC Class B, CCC


Description

Book size Kabylake high end signage player, Intel 7th generation core processor



·         Intel 7th generation core processor

·         2 x SO-DIMM DDR3L/DDR4 Memory,Up to 32GB

·         1 x DP,1 x HDMI, Supporting 4K Display

·         1 x 2.5” SATA, 1 x mSATA, 1 x M.2 (2242/2280)

·         3 x USB 3.0, 3 x USB2.0, 1 x RS232

·         1 x RJ45,1 x Mini-PCIe for WiFi/BT/3G/4G, 1 x SIM Slot
pdf
Data Sheet
