• Each unit supports 5 x 10/100/1000Base-T(X) ports or 4 x 10/100/1000Base-T(X) and 1 x 1000Base-X SFP ports • Support Jumbo Frame up to 9K Bytes • Hardware DIP switch to enable/disable warning function • Rigid IP-30 slim type housing design • DIN-Rail and wall mounting enabled • Relay output to carry capacity of 1A at 24 VDC
More Information
Specifications
Physical Ports
1000Base-X SFP Ports
1
10/100/1000Base-T(X) Ports in RJ45 Auto MDI/MDIX
4
Technology
Ethernet Standards
IEEE 802.3 for 10Base-T IEEE 802.3u for 100Base-TX IEEE 802.3z for 1000Base-X IEEE 802.3ab for 1000Base-T IEEE 802.3x for Flow control
MAC Table
1024 MAC addresses
Processing
Store-and-Forward
Jumbo Frame
9K
LED Indicators
Power Indicator
Green : Power LED x 2
Fault Indicator
Amber : Indicates PWR1 or PWR2 failure occurred
1000Base-X SFP Port Indicator
Green for port Link/Act
10/100/1000Base-T(X) RJ45 Port Indicator
Green for port Link / Act Amber for 100Mbps indicator
Fault Contact
Relay
Relay output to carry capacity of 1A at 24VDC
Power
Redundant Input Power
Dual DC inputs. 12~48 VDC on 6-pin terminal block
Power Consumption (Typ.)
5.5 Watts
Overload Current Protection
Present
Reverse Polarity Protection
Present
Physical Characteristics
Enclosure
IP-30
Dimensions (W x D x H)
26.1(W) x 94.9(D) x 144.3(H) mm ( 1.03x3.74x5.68 inch.)
