IGS-150B 5-port unmanaged Gigabit Ethernet switch
IGS-150B 5-port unmanaged Gigabit Ethernet switch
Industrial 5-port mini type unmanaged Gigabit Ethernet switch with 5x10/100/1000Base-T(X)
-
SKU
-
IGS-150B
Have a Question about this product?
Description /
IGS-150B 5-port unmanaged Gigabit Ethernet switch
More Information
| Specifications |
| Physical Ports | | | 10/100/1000Base-T(X) Ports in RJ45 Auto MDI/MDIX | 5 | | Technology | | | Ethernet Standards | IEEE 802.3 for 10Base-T
IEEE 802.3u for 100Base-TX
IEEE 802.3ab for 1000Base-T
IEEE 802.3x for Flow control | | MAC Table | 4K | | Packet buffer | 128K bytes | | Processing | Store-and-Forward | | Jumbo Frame | 9720 bytes | | Switch Properties | Switching latency: 7 us
Switching bandwidth: 10Gbps Throughput (packet per second) : 7.24Mpps@64Bytes packet | | LED Indicators | | | Power Indicator | Green : Power LED x 2 | | 10/100/1000Base-T(X) RJ45 Port Indicator | Up Green LED for Link/Act indicator
Lower LED for speed indicator: Green for 1Gbps, Amber for 100Mbps, Off-light for 10Mbps | | Power | | | Redundant Input Power | Dual 12~48VDC on 4-pin terminal block. | | Power Consumption (Typ.) | <4.4Watts, 0.29-0.09A | | Overload Current Protection | Present | | Reverse Polarity Protection | Present | | Physical Characteristics | | | Enclosure | IP-30 | | Dimensions (W x D x H) | 26.1 (W) x 70 (D) x 95(H) mm (1.03 x 2.76 x 3.74 inch) | | Weight (g) | 222 g | | Hardware Version | 1.0 | | Environmental | | | Storage Temperature | -40 to 85°C (-40 to 185°F) | | Operating Temperature | -40 to 75°C (-40 to 167°F) | | Operating Humidity | 5% to 95% Non-condensing | | Regulatory Approvals | | | EMC | CE EMC (EN 55024, EN 55032), FCC Part 15 B | | EMI | EN 55032, CISPR32, EN 61000-3-2, EN 61000-3-3, FCC Part 15 B class A | | EMS | EN 55024 (IEC/EN 61000-4-2 (ESD: Contact 4KV, Air 8KV), IEC/EN 61000-4-3 (RS: 3V),IEC/EN 61000-4-4 (EFT Power 0.5KV, Signal 0.5KV), IEC/EN 61000-4-5 (Surge: Power 0.5KV, Signal 1KV), IEC/EN 61000-4-6 (CS: 3V), IEC/EN 61000-4-8(PFMF), IEC/EN 61000-4-11 (DIP)) | | Shock | IEC60068-2-27 | | Free Fall | IEC60068-2-31 | | Vibration | IEC60068-2-6 | | Safety | EN60950-1 (LVD), UL61010-1, UL61010-2-201 | | MTBF | 2,556,319hrs | | Warranty | 5 years | |
