IGS-C1080 8-port Unmanaged Gigabit Industrial Switch

Oring

Industrial 8-port unmanaged Gigabit Ethernet switch

Key Features:

  • Supports 8 x 10/100/1000Base-T(X), RJ45 connector
  • Compact size for easy installation
  • QoS supported to process critical data in heavy traffic
  • IP40 protection class
  • -40 to 75°C wide operating temperature range
  • DIN-Rail mounting enabled

In stock

SKU
IGS-C1080
$265.00

Have a Question about this product?

This form is protected by reCAPTCHA - the Google Privacy Policy and Terms of Service apply.

Description / IGS-C1080 8-port Unmanaged Gigabit Industrial Switch

The IGS-C1080 line of gigabit Ethernet switches have 8 x10/100/1000Base-T(X) RJ45 ports and are unmanaged. A broad operating temperature range of -40°C to 75°C can also accommodate the majority of operating environments. As a result, the switch is among the most trustworthy options for Ethernet applications.

Key Features:

  • Supports 8 x 10/100/1000Base-T(X), RJ45 connector
  • Compact size for easy installation
  • QoS supported to process critical data in heavy traffic
  • IP40 protection class
  • -40 to 75°C wide operating temperature range
  • DIN-Rail mounting enabled

More Information

brand Oring
Specifications
ORing Switch Model IGS-C1080
Physical Ports

10/100/1000Base-T(X) Ports in RJ45 Auto MDI/MDIX

 8
Technology
Ethernet Standards IEEE 802.3 for 10Base-T
IEEE 802.3u for 100Base-TX
IEEE 802.3ab for 1000Base-T
IEEE 802.3x for Flow control
MAC Table 4k
Packet Buffer Size 1.5Mbits
Processing Store-and-Forward
DIP Switch Quality of Service (QoS), Broadcast Storm Protection (BSP)
Power
Single Input Power 12~48VDC on 2-pin terminal block.
Overload Current Protection Present
Reverse Polarity Protection Present
Physical Characteristics
Enclosure IP-40
Dimensions (W x D x H) 43.5 × 103 × 64mm
Environmental
Storage Temperature -40 to 85°C (-40 to 185°F)
Operating Temperature -40 to 75°C (-40 to 167°F)
Operating Humidity 5% to 95% Non-condensing
Regulatory Approvals
EMC CE EMC (EN 55032, EN 55035), FCC Part 15 B
EMI CISPR32, EN 61000-3-2, EN 61000-3-3, FCC Part 15 B class A
EMS

EN61000-4-2 (ESD), EN61000-4-3 (RS), EN61000-4-4 (EFT), EN61000- 4-5 (Surge), EN61000-4-6 (CS), EN61000-4-8(PFMF)
Safety EN62368-1
Description

The IGS-C1080 line of gigabit Ethernet switches have 8 x10/100/1000Base-T(X) RJ45 ports and are unmanaged. A broad operating temperature range of -40°C to 75°C can also accommodate the majority of operating environments. As a result, the switch is among the most trustworthy options for Ethernet applications.

Key Features:

  • Supports 8 x 10/100/1000Base-T(X), RJ45 connector
  • Compact size for easy installation
  • QoS supported to process critical data in heavy traffic
  • IP40 protection class
  • -40 to 75°C wide operating temperature range
  • DIN-Rail mounting enabled
pdf
Datasheet
