Shop IPES-3424DSFP-2P - 28 port, PoE, managed switch

- High-density 10/100TX L2+ managed PoE at/af switch
- Enhanced G.8032 ring protection < 20ms with easy configuration; Dynamic coupling ring; Aggregation ring*
- Supports PoE management

In stock

SKU: IPES-3424DSFP-2P

Have a Question about this product?

Name *

Phone *

Email *

Postcode *

Message *

This form is protected by reCAPTCHA - the Google Privacy Policy and Terms of Service apply.

Description / IPES-3424DSFP-2P - 28 port, PoE, managed switch

_{IEEE Standards}

_{IEEE 802.3 10Base-T Ethernet}
_{IEEE 802.3u 100Base-TX Ethernet}
_{IEEE 802.3z 1000Base-X Ethernet}
_{IEEE 802.3x Flow Control Capability}
_{ANSI/IEEE 802.3 Auto-negotiation}
_{IEEE 802.1Q VLAN}
_{IEEE 802.1p Class of Service}
_{IEEE 802.1X Access Control}
_{IEEE 802.1D Spanning Tree}
_{IEEE 802.1w Rapid Spanning Tree}
_{IEEE 802.1s Multiple Spanning Tree}
_{IEEE 802.3ad Link Aggregation Control Protocol (LACP)}
_{IEEE 802.1AB Link Layer Discovery Protocol (LLDP)}
_{IEEE 802.1x User Authentication (Radius)}
_{IEEE 802.3t/af Power Over Ethernet}

_{Switch Architecture}

_{Back-plane (Switching Fabric): 56Gbps}
_{Packet throughput ability (Full-Duplex): 71.43Mpps @64bytes}

_{Transfer Rate}

_{14,880pps for Ethernet port}
_{148,800pps for Fast Ethernet port}
_{1,488,000pps for Gigabit Ethernet port}

_CPU

_{Marvell 800Mhz}

_RAM

_{256M Byte}

_Flash

_{128M Byte}

_{Mac Address}

_{16K MAC address table}

_{Jumbo frame}

_{9KB on all ports}

_{PoE pin assignment}

_{RJ-45 port # 1~# 24 support PoE at/af End-point,}
_{Alternative A mode. Per port provides up to 30W@54V capability.}
_{Positive (VCC+): RJ-45 pin 1,2.}
_{Negative (VCC-): RJ-45 pin 3,6.}

_{PoE input voltage & Power feed voltage}

_{Input V}	_{Active Mode A /Output V}
_45~56V(af)	_48V@15W
_54~56V(at)	_54V@30W

_Connectors

_{24 10/100TX RJ-45 with auto MDI/MDI-X function}
_{4 100M / 1000M Mini-GBIC : SFP sockets}
_{RS-232 console: Female DB-9}
_{USB for backup and restore}

_DDM

_{Conform to SFF-8472 to show diagnostic SFP with temperature, current, voltage, input and output power}

_Protocol

_CSMA/CD

_LED

_{Per unit: Power 1 (Green), Power 2 (Green), Alarm (Red) ,R.M (Green)}
_{Link/Activity (Green), Full duplex/collision(Yellow)), MINI GBIC (Link/Activity )(Green)}

_{Power Supply}

_{Two power sockets for switch system,}
_{9.5~60VDC input}
_{IEC320 85~265VAC input (-AC model)}
_{AC/DC 85~265VAC/100V~370VDC input (-HV model)}
_{48VDC for PoE}

_{Power Consumption}

_{Full load: 30W/ Unload: 13W}

_{PoE Power Budget}

_720W

_{Relay Alarm}

_{Provides one relay output for port breakdown, power fail and alarm.}
_{Alarm Relay current carry ability: 1A @ DC24V}

_DI/DO

_{2 Digital Input (DI) :}
_{Level 0: -30~2V / Level 1: 10~30V}
_{Max. input current:8mA}
_{2 Digital Output(DO): Open collector to 40 VDC, 200mA}

_RTC

_{RTC(Real Time Clock) to keep track of time always}

_{Factory reset button & watch dog design}

_{Factory reset button to restore back to factory default settings. Watch dog design can reboot switch automatically when CPU is found dead}

_{Case Dimension}

_{19” Metal case,IP-30; 440mm(W)x325mm(D)x44mm(H)}

_{Operating Humidity}

_{5%~95% (Non-condensing)}

_{Operating Temperature}

_{Standard: -40°C ~60°C}
_{Extended temperature : -40°C ~75°C}

_{Storage Temperature}

_{-40°C ~85°C}

_EMI

_{FCC Class A, CE EN61000-4-2 (ESD),}
_{CE EN61000-4-3 (RS), CE EN-61000-4-4 (EFT),}
_{CE EN61000-4-5 (Surge), CE EN61000-4-6 (CS),}
_{CE EN61000-4-8, CE EN61000-4-11,}
_{CE EN61000-4-12, CE EN61000-6-2,}
_{CE EN61000-6-4}

_{Stability Testing}

_{IEC60068-2-32 (Free fall), IEC60068-2-27 (Shock), IEC60068-2-6 (Vibration), KEMA 61850-3,}
_{IEEE1613, Zero packet loss(240~480V)}
_{IEC60870-2-2, IEC60068-2-30}

_Warranty

_{5 years}
