MTS952T & MTS952T-I

SATA III M.2 SSD in std and wide temp in sizes from 64GB to 2TB

In stock

SKU
MTS952T & MTS952T-I

Have a Question about this product?

This form is protected by reCAPTCHA - the Google Privacy Policy and Terms of Service apply.

Description / MTS952T & MTS952T-I

Transcend's MTS952T M.2 SSD features the SATA III 6Gb/s interface and state-of-the-art 3D NAND technology, which allows 96 layers of 3D NAND flash chips to be vertically stacked. Compared to BiCS3 NAND at 64 layers, this density breakthrough greatly improves storage efficiency. The MTS952T is built with DRAM cache for fast access, and is fully tested in-house to guarantee reliability in mission-critical applications, boasting an endurance rating of 3K Program/Erase cycles.

More Information

Specifications

Appearance
Dimensions 80.0 mm x 22.0 mm x 3.58 mm (3.15" x 0.87" x 0.14")
Weight 9 g (0.32 oz)
Form Factor
  • M.2
M.2 Type
  • 2280-D2-B-M

Interface
Bus Interface
  • SATA III 6Gb/s

Storage
Flash Type
  • 3D TLC NAND flash
Capacity
  • 64 GB/
  • 128 GB/
  • 256 GB/
  • 512 GB/
  • 1 TB/
  • 2 TB

Operating Environment
Operating Voltage
  • 3.3V±5%
Operating Temperature
  • Standard
    0°C (32°F) ~ 70°C (158°F)
  • Wide Temp.
    -40°C (-40°F) ~ 85°C (185°F)
Storage Temperature -40°C (-40°F) ~ 85°C (185°F)
Humidity 5% ~ 95%
Shock
  • 1500 G, 0.5 ms, 3 axis
Vibration (Operating) 2.17 G (peak-to-peak), 10 Hz ~ 700 Hz (frequency)

Power
Power Consumption (Operation) 2.1 watt(s)
Power Consumption (Sleep) 0.3 watt(s)

Performance
Sequential Read/Write (CrystalDiskMark, max.) Read: 560 MB/s
Write: 520 MB/s
4K Random Read/Write (IOmeter, max.) Read: 95,000 IOPS
Write: 85,000 IOPS
Mean Time Between Failures (MTBF) 3,000,000 hour(s)
Terabytes Written (Max.) 3,520 TB
Drive Writes Per Day (DWPD) 1.61 (3 yrs)
Note
  • Speed may vary due to host hardware, software, usage, and storage capacity.
  • The workload used to rate DWPD may be different from your actual workload, which may vary due to host hardware, software, usage, and storage capacity.
Description

Transcend's MTS952T M.2 SSD features the SATA III 6Gb/s interface and state-of-the-art 3D NAND technology, which allows 96 layers of 3D NAND flash chips to be vertically stacked. Compared to BiCS3 NAND at 64 layers, this density breakthrough greatly improves storage efficiency. The MTS952T is built with DRAM cache for fast access, and is fully tested in-house to guarantee reliability in mission-critical applications, boasting an endurance rating of 3K Program/Erase cycles.
pdf
Data Sheet
