Shop PICO313 - Pentium N4200/Celeron N3350 CPU

Axiomtek

Pico-ITX SBC with Intel® Pentium® Processor N4200 & Celeron® Processor N3350, LVDS and LAN

In stock

Name *

Phone *

Email *

Postcode *

Message *

This form is protected by reCAPTCHA - the Google Privacy Policy and Terms of Service apply.

Description / PICO313 - Pentium N4200/Celeron N3350 CPU

Intel® Pentium® processor N4200 and Celeron® processor N3350

1 DDR3L SO-DIMM, up to 8GB

1 USB 2.0 port

2 PCI Express Mini Card slots

Brand

Axiomtek

Specifications

CPU	Intel® Pentium® N4200 and Celeron® N3350 processor onboard
Chipset	SoC integrated
System Memory	1 x 204-pin SO-DIMM DDR3L-1867, up to 8GB
BIOS	AMI
COM	N/A
USB	1 x USB 2.0
Ethernet	1 x10/100/1000 Mbps (Intel® i211AT)
Display	1 x LVDS
Digital I/O	4-channel in/out programmable
Audio	N/A
Storage	1 x SATA-600
Expansion	1 x Full-size PCI Express Mini Card with mSATA supported 1 x Half-size PCI Express Mini Card 1 x PCIe x1, 1 x LPC, 1 x DDI, 4 x USB 3.0,1 x HD audio and 1 x SMBus (through expansion connector)
Others	TPM 1.2
Battery	Lithium 3V/220mAH
Power Input	1 x 4 pin connector +12V DC-in only AT Auto Power On function supported
Power Requirements	Intel® Pentium® N4200 @8GB DDR3L Max. RMS. +12V @ 1.6A Intel® Celeron® N3350 @8GB DDR3L Max. RMS. +12V @ 1.4A
Watchdog Timer	65535 levels, 1 ~ 65535 sec.
Hardware Monitoring	Yes
Operating Temperature	-20°C ~ +70°C (-4°F ~ +158°F)
Relative Humidity	10% ~ 95% relative humidity, non-condensing
Dimensions	100 x 72 mm
Board Thickness	1.6 mm
Certifications	CE

Description

Intel® Pentium® processor N4200 and Celeron® processor N3350

1 DDR3L SO-DIMM, up to 8GB

1 USB 2.0 port

2 PCI Express Mini Card slots
