SDM-S - smart display module

Giada Technology Inc.

SDM-S, Intel Atom Cherry Trail Z8350 CPU, DDR3L 2GB, eMMC onboard 32GB, SDM Standard I/O.

In stock

SKU
SDM-S - smart display module

Have a Question about this product?

This form is protected by reCAPTCHA - the Google Privacy Policy and Terms of Service apply.

Description / SDM-S - smart display module

SDM Z8350, a new product of Intel's recently-released SDM-S specification (Intel Smart Display Module), adopts Intel Atom Cherry Trail Z8350 CPU. The module (109mm × 60mm), is roughly the size of a credit card. It can be integrated into IoT applications as it has no housing. The module incorporates high-speed PCIe connectivity with a custom I/O receptacle board that eliminates the need for external I/O. It is optimized for applications like digital signage, public kiosks and professional monitors, point-of-sale, projectors, bedside terminals as well as for the trade and the hospitality industry.

More Information

brand Giada Technology Inc.
Specifications
SDM-S SDM-S Z8350
Processor CPU Intel® Atom x5-Z8350
Frequency 1.44GHz (Up to 1.92GHz )
BIOS AMI Source Code
Chipset SOC
Memory Type DDR3L-1600MHz
Socket Onboard
Size 2GB
Graphics GPU Intel® HD Graphics 400
Graphic Engine DirectX11, OpenGL4.0 and OpenCL 1.2
Main Chip Network Controller  Realtek RTL8111H Gigabit Ethernet
WiFi+BT on Board RL-SM02BD-8723BS for WiFi+BT
Storage eMMC 32GB

SDM I/O

(PCIe x8 Edge Connector)

 USB 3.0 1 x USB3.0
HDMI 1 x HDMI(PCIe)(Max.2560 x 1600@24Hz)
DP 1 x DP(PCIe)(Max.4096 x 2304@60Hz)
Serial Port 1 x COM
Rear I/O USB 2.0 2 x USB2.0
LAN 1 x RJ45
JAHC Tech WatchDog Timer 0~255 Second Time Out Support
Auto Power On Power Activated Automatically Start
RTC Set Up Independently Every day, A Week as a Cycle
Operation System

 Windows Windows 8.1/10(64-bit)
Linux Supported
Android Android 5.1
Power Power Type SDM I/O
Input Voltage 12V/3.3A
Dimensions Length x Width 109.9mm x 60mm(4.33"x2.36")
Environment
 Storage Temperature -40 ~ 75℃ ( -40 ~ 167° F )
Operating Temperature 0℃ ~ 60℃ ( 32 ~ 140° F )
Relative Humidity 95%@60℃(non condesing)


Description

SDM Z8350, a new product of Intel's recently-released SDM-S specification (Intel Smart Display Module), adopts Intel Atom Cherry Trail Z8350 CPU. The module (109mm × 60mm), is roughly the size of a credit card. It can be integrated into IoT applications as it has no housing. The module incorporates high-speed PCIe connectivity with a custom I/O receptacle board that eliminates the need for external I/O. It is optimized for applications like digital signage, public kiosks and professional monitors, point-of-sale, projectors, bedside terminals as well as for the trade and the hospitality industry.
