TGXPS-141GX-M12 EN50155 5-port unmanaged PoE Ethernet switch

EN50155 5-port unmanaged Gigabit PoE Ethernet switch with 4x10/100/500/1000Base-T(X) P.S.E. and 1x10/100/500/1000Base-T(X), M12 connector, 24VDC power input

In stock

SKU
TGXPS-141GX-M12-xx

Have a Question about this product?

This form is protected by reCAPTCHA - the Google Privacy Policy and Terms of Service apply.

Description / TGXPS-141GX-M12 EN50155 5-port unmanaged PoE Ethernet switch

  • Supports 4 x 10/100/500/1000 Base-T(X) with P.S.E. PoE ports
  • 4 port P.S.E. fully compliant with IEEE802.3at standard, provide up to 30 Watts per port
  • Support auto-negotiation and auto-MDI/MDI-X
  • Support store and forward transmission
  • Support flow control
  • Support broadcast storm protection
  • Ultra-rugged enclosure M12 connector for toughest industrial usages
  • Wall mounting enabled

More Information

Specifications
Physical Ports

10/100/500/1000Base-T(X) with P.S.E. Ports in M12 Auto MDI/MDIX

 4 x M12 female connector (8-pin M12 A-coding)
10/100/500/1000Base-T(X) Port in M12 Auto MDI/MDIX 1 x M12 female connector (8-pin M12 A-coding)
Technology
Ethernet Standards

IEEE 802.3 for 10Base-T.
IEEE 802.3u for 100Base-TX
IEEE 802.3ab for 1000Base-T
IEEE 802.3x for Flow control
IEEE 802.3at PoE specification (up to 30 Watts per port for P.S.E.)
Processing Store-and-Forward
LED Indicators
Power indicator Green: Power LED x 1
10/100/500/1000Base-T(X) M12 port with P.S.E. indicator

Top dual color LED for 10/100/1000Mbps Link/ACT indicator: Green LED for 1000Mbps, Amber for 10/100Mbps
Middle Green for port Link/Act at 500Mbps
Bottom Blue for PoE indicator
10/100/500/1000Base-T(X) M12 port indicator Top dual color LED for 10/100/1000Mbps Link/ACT indicator: Green LED for 1000Mbps, Amber for 10/100Mbps
Bottom Green for port Link/Act at 500Mbps
Power
Input Power

12 ~ 57VDC power input on M12 female connector (5-pin M12 A-coding)

72~110VDC power input on M12 female connector (5-pin M12 A-coding)
Power Consumption (Typ.) 3 Watts (power consumption of P.S.E. is not included) 6 Watts (power consumption of P.S.E. is not included)
PoE Output Power

60 Watts (12~24VDC)
120 Watts (24~57VDC)

 60 Watts
Overload Current Protection Present
Reverse Polarity Protection Present
Physical Characteristics
Enclosure IP-30
Dimensions (W x D x H) 88.9 x 55 x 178.2 mm
Weight (g) 643 g 771 g
Environmental
Storage Temperature -40 to 85°C (-40 to 185°F)
Operating Temperature -40 to 75°C (-40 to 167°F)
Operating Humidity 5% to 95% Non-condensing
Regulatory Approvals
EMI FCC Part 15, CISPR (EN55022) class A, EN50155 (EN50121-3-2, EN55011, EN50121-4)
EMS

IEC61000-4-2 (ESD), IEC61000-4-3 (RS), IEC61000-4-4 (EFT), IEC61000-4-5 (Surge), IEC61000-4-6 (CS), IEC61000-4-8, IEC61000-4-11
Shock IEC60068-2-27, EN61373
Free Fall IEC60068-2-32
Vibration IEC60068-2-6, EN61373
Safety EN60950-1
Warranty 5 years
Description
  • Supports 4 x 10/100/500/1000 Base-T(X) with P.S.E. PoE ports
  • 4 port P.S.E. fully compliant with IEEE802.3at standard, provide up to 30 Watts per port
  • Support auto-negotiation and auto-MDI/MDI-X
  • Support store and forward transmission
  • Support flow control
  • Support broadcast storm protection
  • Ultra-rugged enclosure M12 connector for toughest industrial usages
  • Wall mounting enabled
pdf
Datasheet
