TPM-3617, 17" Stainless steel monitor
TPM-3617, 17" Stainless steel monitor
IP66/69K Protected 17" Stainless Steel Industrial Monitor with P-CAP/5-Wire Resistive
-
SKU
-
TPM-3617, 17" Stainless steel monitor
Have a Question about this product?
Description /
TPM-3617, 17" Stainless steel monitor
IP66/69K Protected Stainless Steel 316 Flat Panel Design
VGA and USB (M12 Connetor), HDMI port
VESA and Yoke mounting
17" LCD, P-CAP or 5-Wire Resistive, Resolution 1280 x 1024 (SXGA)
12 ~ 24 V DC power input (M12 Connector)
More Information
| Specifications |
| Model |
TPM-3617P-B6A1 |
TPM-3617R-B6A1
|
| Display |
Panel Size |
17” |
| Aspect Ratio |
4:3
|
| Resolution |
1280 x 1024 (SXGA)
|
Viewing Angle
|
85 x 85 (H) x 80 x 80 (V)
|
Brightness
|
350 (cd/m2) |
Contrast Ratio
|
1000:1
|
Life Time
|
50,000 hrs
|
| Touchscreen |
Type
|
Projected Capacitive Touch |
5-Wire Resistive
|
Surface Hardness
|
7 Mohs
|
3 Mohs
|
Transparency
|
N/A |
80% (±3%)
|
On/Off Button
|
Yes
|
N/A
|
| I/O Interface |
Video Interface
|
1 VGA (M12 Connector), 1 HDMI (IP67 Waterproof Connector)
|
| Touch Interface |
1 USB (M12 Connector)
|
Audio
|
N/A
|
Speaker
|
N/A
|
2, 2W Amplifier
|
Others
|
N/A
|
| OSD Control |
Function Key
|
1 RS-232, M12 Connector Remote OSD control (Option)
5 Keys: Menu, Up, Down, Auto Adjust, Monitor Power on/off
|
6 Keys: Menu, Up, Down, Auto Adjust, Monitor Power on/off, Funtion Key
|
| Power |
Power Input |
12-24 V DC power input
|
| Power Connector |
M12 connector
|
| Power Consumption |
22 W
|
Mounting
|
VESA Mount
|
75mmx 75mm; 100mm x 100mm
|
Panel Mount
|
N/A
|
Others
|
Yoke mount
|
| Environment |
Operating Temperature |
0~60° C (32~140° F)
|
| Storage Temperature |
-20~60° C (-4~140° F)
|
| Humidity |
5~95% @ 40° C, non-condensing
|
| Vibration |
5-500 Hz, 0.026 G²/Hz, 2.16 Grms, X, Y, Z, 1 hour per axis
|
Shock
|
Full System IP66 Protection , Stainless Steel 316 (IP69K Protection by Option)
|
| General |
Certification |
TBD
|
Material, Surface Finish
|
Stainless Steel 316, Brush Finished
|
True Flat
|
Yes
|
| Ingress Proctetion |
Full System IP66 Protection
|
Dimensions (W x H x D)
|
439 X 373 X 66.9 (17.28” x 14.69” x 2.63”)
|
Net Weight
|
7.71 kg (17.0 lb)
|
Operating System
|
Windows 7/8.1/10, WES7, WE8S, Linux Fedora, Ubuntu |
|
| Description |
IP66/69K Protected Stainless Steel 316 Flat Panel Design
VGA and USB (M12 Connetor), HDMI port
VESA and Yoke mounting
17" LCD, P-CAP or 5-Wire Resistive, Resolution 1280 x 1024 (SXGA)
12 ~ 24 V DC power input (M12 Connector)
|
