TXPS-141XT EN50155 5-port unmanaged PoE Ethernet switch
TXPS-141XT EN50155 5-port unmanaged PoE Ethernet switch
EN50155 5-port unmanaged PoE Ethernet switch with 4x10/100/500Base-T(X) P.S.E. and 1x10/100/500Base-T(X), M12 connector, 24VDC power input
-
SKU
-
TXPS-141XT-M12-xx
Have a Question about this product?
Description /
TXPS-141XT EN50155 5-port unmanaged PoE Ethernet switch
- Supports 4 x 10/100/500 Base-T(X) with P.S.E. PoE ports
- 4 port P.S.E. fully compliant with IEEE802.3at standard, provide up to 30 Watts per port
- Support auto-negotiation and auto-MDI/MDI-X
- Support store and forward transmission
- Support flow control
- Support broadcast storm protection
- Ultra-rugged enclosure M12 connector for toughest industrial usages
- Wall mounting enabled
More Information
| Specifications |
| Physical Ports |
|
|
10/100/500Base-T(X) with P.S.E. Ports in M12 Auto MDI/MDIX
|
4 x M12 female connector (4-pin M12 D-coding) |
| 10/100/500Base-T(X) Port in M12 Auto MDI/MDIX |
1 x M12 female connector (4-pin M12 D-coding) |
| Technology |
|
| Ethernet Standards |
IEEE 802.3 for 10Base-T
IEEE 802.3u for 100Base-TX
IEEE 802.3x for Flow control
IEEE 802.3at PoE specification (up to 30 Watts per port for P.S.E.)
|
| Processing |
Store-and-Forward |
| LED Indicators |
|
| Power indicator |
Green: Power LED x 1 |
| 10/100/500Base-T(X) M12 port with P.S.E. indicator |
Top Green for port Link/Act at 10/100Mbps
Middle Green for port Link/Act at 500Mbps
Bottom Blue for PoE indicator
|
| 10/100/500Base-T(X) M12 port indicator |
Top Green for port Link/Act at 10/100Mbps
Bottom Green for port Link/Act at 500Mbps
|
| Power |
|
| Input Power |
12~57VDC power input on M12 female connector (5-pin M12 A-coding)
|
72~110VDC power input on M12 female connector (5-pin M12 A-coding)
|
| Power Consumption (Typ.) |
2 Watts |
5 Watts |
| PoE Output Power |
60 Watts (12~24VDC)
120 Watts (24~57VDC)
|
60 Watts |
| Overload Current Protection |
Present |
| Reverse Polarity Protection |
Present |
| Physical Characteristics |
|
| Enclosure |
IP-30 |
IP-40 |
| Dimensions (W x D x H) |
88.9 x 55 x 178.2 mm |
| Weight (g) |
643 g |
771 g |
| Environmental |
|
| Storage Temperature |
-40 to 85°C (-40 to 185°F) |
| Operating Temperature |
-40 to 75°C (-40 to 167°F) |
| Operating Humidity |
5% to 95% Non-condensing |
| Regulatory Approvals |
|
| EMI |
FCC Part 15, CISPR (EN55022) class A, EN50155 (EN50121-3-2, EN55011, EN50121-4) |
| EMS |
EN61000-4-2 (ESD), EN61000-4-3 (RS), EN61000-4-4 (EFT), EN61000-4-5 (Surge), EN61000-4-6 (CS), EN61000-4-8, EN61000-4-11
|
| Shock |
IEC60068-2-27, EN61373 |
| Free Fall |
IEC60068-2-32 |
| Vibration |
IEC60068-2-6, EN61373 |
| Safety |
EN60950-1 |
| Warranty |
5 years |
|
| Description |
- Supports 4 x 10/100/500 Base-T(X) with P.S.E. PoE ports
- 4 port P.S.E. fully compliant with IEEE802.3at standard, provide up to 30 Watts per port
- Support auto-negotiation and auto-MDI/MDI-X
- Support store and forward transmission
- Support flow control
- Support broadcast storm protection
- Ultra-rugged enclosure M12 connector for toughest industrial usages
- Wall mounting enabled
|
