USD240I microSD Cards

Transcend

112-layer 3D NAND flash with SLC Mode technology -40℃~85℃ microSDXC memory card

Key Features:

  • Built-in LDPC ECC (Error Correction Code) functionality
  • Early Move
  • Supports S.M.A.R.T. function to conduct health monitoring, analysis, and reporting for storage devices
  • Wear-Levelling
  • Compliant with RoHS 2.0 standards
  • Electrostatic protection (ESD IEC 61000-4-2)
  • Compliant with SD specification 6.1
  • Compliant with UHS-I
  • Compliant with Video Speed Class 30 (V30)
  • Compliant with Application Performance Class 2 (A2)
  • Endurance: 100K P/E cycles (Program/Erase cycles) guaranteed
  • Promised operational reliability in a wide temperature range (from -40°C to 85°C)

In stock

SKU
TSxxxxUSD240I

Have a Question about this product?

This form is protected by reCAPTCHA - the Google Privacy Policy and Terms of Service apply.

Description / USD240I microSD Cards

Transcend's USD240I microSDXC memory card combines the benefits of high performance and exceptional endurance at a reasonable price. It uses premium 112-layer 3D NAND flash with SLC Mode technology and is rated to withstand 100K P/E cycles. With a broad operating temperature range of -40°C to 85°C, Transcend's microSDXC USD240I is perfect for write-intensive apps like outdoor transportation, surveillance systems, digital signage, and POS terminals.

Key Features:

  • Built-in LDPC ECC (Error Correction Code) functionality
  • Early Move
  • Supports S.M.A.R.T. function to conduct health monitoring, analysis, and reporting for storage devices
  • Wear-Levelling
  • Compliant with RoHS 2.0 standards
  • Electrostatic protection (ESD IEC 61000-4-2)
  • Compliant with SD specification 6.1
  • Compliant with UHS-I
  • Compliant with Video Speed Class 30 (V30)
  • Compliant with Application Performance Class 2 (A2)
  • Endurance: 100K P/E cycles (Program/Erase cycles) guaranteed
  • Promised operational reliability in a wide temperature range (from -40°C to 85°C)


More Information

brand Transcend
Specifications

Appearance

Dimensions

11 mm x 15 mm x 1 mm (0.43" x 0.59" x 0.04")
Form Factor
  • microSD flash card

Storage
Flash Type
  • 112-layer 3D NAND flash (SLC mode)
Capacity
  • 20 GB/
  • 40 GB/
  • 80 GB/
  • 160 GB

Operating Environment
Operating Voltage
  • 2.7V ~ 3.6V
Drop Test
  • 1.5m free fall
Operating Temperature
  • Wide Temp.
    -40°C (-40°F) ~ 85°C (185°F)
Storage Temperature -40°C (-40°F) ~ 85°C (185°F)
Humidity 0% ~ 95%
Shock
  • Acceleration: 490 m/s² (standard holding time: 11 ms, semi-sine wave, velocity change: 3.44 m/s)
Vibration (Operating) 20 G (peak-to-peak), 10 Hz ~ 2,000 Hz (frequency)

Power
Power Consumption (Max.) 2.88 watt(s)

Performance
Read Speed (Max.) up to 100 MB/s
Write Speed (Max.) up to 80 MB/s
Terabytes Written (TBW) up to 6,763 TBW
Note
  • Speed may vary due to host hardware, software, usage, and storage capacity.
  • Terabytes Written (TBW) expresses endurance under the highest capacity.
Description

Transcend's USD240I microSDXC memory card combines the benefits of high performance and exceptional endurance at a reasonable price. It uses premium 112-layer 3D NAND flash with SLC Mode technology and is rated to withstand 100K P/E cycles. With a broad operating temperature range of -40°C to 85°C, Transcend's microSDXC USD240I is perfect for write-intensive apps like outdoor transportation, surveillance systems, digital signage, and POS terminals.

Key Features:

  • Built-in LDPC ECC (Error Correction Code) functionality
  • Early Move
  • Supports S.M.A.R.T. function to conduct health monitoring, analysis, and reporting for storage devices
  • Wear-Levelling
  • Compliant with RoHS 2.0 standards
  • Electrostatic protection (ESD IEC 61000-4-2)
  • Compliant with SD specification 6.1
  • Compliant with UHS-I
  • Compliant with Video Speed Class 30 (V30)
  • Compliant with Application Performance Class 2 (A2)
  • Endurance: 100K P/E cycles (Program/Erase cycles) guaranteed
  • Promised operational reliability in a wide temperature range (from -40°C to 85°C)

pdf
Datasheet
