VTC210 Fanless In-Vehicle Computer with ARM Quad-core Cortex-A53
Fanless In-Vehicle Computer with ARM Quad-core Cortex-A53
In stock
- SKU
- VTC210
Have a Question about this product?
Description / VTC210 Fanless In-Vehicle Computer with ARM Quad-core Cortex-A53
The VTC 210 has a quad-core ARM Cortex-A53 processor with advanced graphics and multimedia capabilities. The VTC 210 is a rugged, fanless, and compact computer inclosure designed for vehicles with limited space. It ships with an advanced GPS receiver that supports GPS/Glonass/QZSS/Galileo/Beidou by default. With an onboard micro-SIM slot, the VTC 210 offers WLAN and WWAN wireless data and voice connectivity.
VTC 210 provides SDK control API such as integration modules power/reset on/off, WDT control, ignition delay timer, and so on for better vehicle protection and control. The VTC 210 is designed to meet a variety of telematics applications, including infotainment, fleet management, dispatching, and mobile video surveillance.
Key Features:
- Built-in Rockchip RK3328 Quad-core ARM® Cortex®-A53 processor
- up to 1.5GHz
- Built-in u-Blox NEO-M8N GPS
- 1 x DB9 for full RS232
- 1 x HDMI, (BOM option VGA + Audio)
- WLAN module option (USB interface)
- 1 x M.2 Key B for WWAN with 1 x internal Micro SIM slot
- SDK for power/reset/WDT/IGN/UVP threshold/GNSS on/off control
- Wide operating temperature 0°C ~ 70°C
- Wide range DC input from 9V ~ 36V
- Certified by CE/FCC/E13
More Information
| Brand | Nexcom | ||||||||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Specifications |
|
||||||||||||||||||||||||||||
| Description | The VTC 210 has a quad-core ARM Cortex-A53 processor with advanced graphics and multimedia capabilities. The VTC 210 is a rugged, fanless, and compact computer inclosure designed for vehicles with limited space. It ships with an advanced GPS receiver that supports GPS/Glonass/QZSS/Galileo/Beidou by default. With an onboard micro-SIM slot, the VTC 210 offers WLAN and WWAN wireless data and voice connectivity. VTC 210 provides SDK control API such as integration modules power/reset on/off, WDT control, ignition delay timer, and so on for better vehicle protection and control. The VTC 210 is designed to meet a variety of telematics applications, including infotainment, fleet management, dispatching, and mobile video surveillance. Key Features:
|
